YouRF Transceiver 802.15.4G

 Transceiver 802.15.4G

The RF Transceiver (B130RF15P4G)is a dual band (sub-1GHz and 2.4GHz band) integrated transceiver specially designed for smart metering and IEEE 802.15.4g related applications.

The RF Transceiver provides high performance, low-cost, generic RF front-end that allows several constant and non-constant envelope modulation schemes to be handled, such as the MR-FSK, MR-OFDM and MR-O-QPSK PHYs of the IEEE 802.15.4g standard for Smart UtilityNetworks (SUN) and Smart grid applications in the 850 - 928 MHz and 2.4GHz license-exempt frequency bands.

The supply voltage ranges from 3.0V to 3.6V. A 36MHz temperature-controlled oscillator (TCXO) or a crystal oscillator (XTAL) is used as a reference clock.

RF Transceiver IP
